HEATING GLASS GLAZING

Heating glass EGLAS from Saint Gobain is an active glass whose task is to heat the interior. Thanks to their functions, they will allow you to eliminate such inconvenience as condensation of steam or snow cover on a skylight or roof. In addition, you can get thermal comfort in your customers' rooms. When applying the right conditions, this glass can even act as the main heating source. The principle of glass operation is based on the use of electric current and a metal oxide coating that covers one surface.

Main benefits:

• thermal comfort
• no drafts, no sense of cold
• water vapor elimination
• melting snow on skylights and roofs
• ease of cleaning glass surfaces

Specification:

PARAMETERS                                                EGLAS composite glass                                EGLAS laminated glass

THICKNESS                                                          16mm-60mm                                                     EGLAS 44.4; 10mm

                                                                                                                                                         EGLAS 66.4; 14mm

DIMENSIONS maximum dimensions of 4mm EGLAS glass: 1800mm x 2800mm

Maximum dimensions of EGLAS glass with a thickness of 6mm 2200mm x 4000mm



Minimum dimensions 300mm x 500mm

POWER SOURCE VOLTAGE standard 230 VAC, optional transformers

GLASS SURFACE TEMPERATURE 45°C

CONDENSATION LIMITATION FUNCTION 50-150W/m²

THERMAL COMFORT FUNCTION 80-250 W/m²

THERMAL FUNCTION 100-300 W/m²

SNOW MELTING FUNCTION 350- 600 W/m²
